| 1 |
800097972
|
Cylinder assy
|
€0.00 |
|
| 1 |
800098541
|
Cylinder assy
|
€0.00 |
|
| 2 |
161540702
|
Gasket
|
€7.59 |
|
| 3 |
61N115195
|
Nut
|
€0.46 |
|
| 4 |
161533201
|
Stud bolt (L= 84 mm)
|
€27.60 |
|
| 5 |
800081650
|
Studbolt (L= 180 mm)
|
€5.29 |
|
| 6 |
Z00062728
|
Screw, M6-L20
|
€0.12 |
|
| 7 |
800088167
|
Clamp
|
€3.68 |
|
| 8 |
800077108
|
Complete tensioner
|
€0.00 |
|
| 9 |
800077109
|
Gasket
|
€0.00 |
|
| 10 |
161535902
|
Screw
|
€4.83 |
|
| 11 |
800045194
|
Washer
|
€0.92 |
|
| 12 |
800081151
|
Chain slider
|
€58.88 |
|
| 13 |
8000H0278
|
Bushing
|
€2.30 |
|
| 14 |
800019789
|
O-Ring
|
€0.23 |
|
| 15 |
80A066222
|
Union
|
€68.77 |
|
| 16 |
Z00062727
|
Screw
|
€0.12 |
|
| 17 |
60N102511
|
Screw
|
€0.46 |
|
| 18 |
Z00062725
|
SCREW TEF M6X1.00X10 CH8
|
€0.12 |
|
| 19 |
8A0015960
|
Washer
|
€3.22 |
|
| 20 |
60N102557
|
Screw (M8x30mm)
|
€0.69 |
|
| 21 |
800008536
|
Washer
|
€0.58 |
|
| 22 |
800033279
|
Clamp ("MIKUNI" carburetor)
|
€3.22 |
|
| 22 |
800060558
|
Clamp("DELL'ORTO" carburetor)
|
€5.29 |
|
| 23 |
800087139
|
Union("DELL'ORTO" carburetor)
|
€85.10 |
|
| 23 |
800085388
|
Union ("MIKUNI" carburetor)
|
€0.00 |
|
| 24 |
800069156
|
Washer
|
€13.57 |
|
| 25 |
161535101
|
Nul
|
€44.85 |
|
| 26 |
800081645
|
Head and cover assy
|
€785.91 |
|
| 27 |
8B0080661
|
Valve guide (+ 0,050 mm)
|
€41.63 |
|
| 27 |
8A0080661
|
Valve guide (+ 0,025 mm)
|
€41.63 |
|
| 28 |
800059940
|
Snap ring
|
€0.46 |
|
| 29 |
800073482
|
Plate
|
€4.95 |
|
| 30 |
800014837
|
Screw
|
€0.23 |
|
| 31 |
62N015672
|
Washer
|
€0.35 |
|
| 32 |
800077425
|
Half cone
|
€3.45 |
|
| 33 |
800081799
|
Cup
|
€19.55 |
|
| 34 |
800082205
|
Spring
|
€0.00 |
|
| 35 |
800082204
|
Spring
|
€11.50 |
|
| 36 |
800081647
|
Cup
|
€6.56 |
|
| 37 |
800075584
|
Seal ring
|
€5.52 |
|
| 37 |
161530301
|
Seal ring
|
€0.00 |
|
| 38 |
161795501
|
Bushing
|
€1.61 |
|
| 39 |
Z00062730
|
SCREW TE M6X1X30 CH8
|
€0.23 |
|
| 40 |
800066395
|
Union
|
€20.70 |
|
| 41 |
8A0015960
|
Washer
|
€3.22 |
|
| 42 |
80B075766
|
Pump body
|
€88.78 |
|
| 43 |
Z00042278
|
Nut
|
€0.12 |
|
| 44 |
8A0063644
|
Gasket
|
€2.30 |
|
| 45 |
8A0060415
|
Rotor
|
€15.76 |
|
| 46 |
800053339
|
Seal ring
|
€6.67 |
|
| 47 |
800063817
|
Bushing
|
€13.80 |
|
| 48 |
161170801
|
Bushing
|
€1.96 |
|
| 49 |
800059942
|
O-Ring
|
€0.58 |
|
| 50 |
800018422
|
O-Ring
|
€0.23 |
|
| 51 |
8A0078765
|
Pipe
|
€22.31 |
|
| 52 |
800080532
|
Exhaust valve
|
€0.00 |
|
| 53 |
800080531
|
Inlet valve
|
€0.00 |
|
| 54 |
800064726
|
Gasket
|
€40.02 |
|
| 55 |
8000A1373
|
Engine assy
|
€0.00 |
|
| 55 |
8000A1364
|
Engine assy
|
€0.00 |
|
| 56 |
800091260
|
Engine gasket set
|
€0.00 |
|
| 57 |
8000H9064
|
Chain slider
|
€23.23 |
|
| 58 |
8A0080669
|
Exhaust valve seat (+0,03 mm)
|
€28.41 |
|
| 58 |
8B0080669
|
Exhaust valve seat (+0,06 mm)
|
€28.41 |
|
| 59 |
8B0080668
|
Inlet valve seat (+0,06 mm)
|
€28.41 |
|
| 59 |
8A0080668
|
Inlet valve seat (+0,03 mm)
|
€30.94 |
|
| 60 |
800090506
|
Gasket(25 kW)
|
€0.00 |
|
| 61 |
800090339
|
Flange(25 kW)
|
€0.00 |
|
| 62 |
800019965
|
O-Ring ("MIKUNI" carburetor)
|
€1.50 |
|
