| 1 |
H8000H1691
|
FRAME
|
TC-TXC |
€
0.00
|
|
|
| 1 |
H8000H1694
|
FRAME WITH BEARING
|
SMR-TE |
€
0.00
|
|
|
| 2 |
H8000H1652
|
REAR FRAME
|
SMR |
€
0.00
|
|
|
| 2 |
H8000H1651
|
REAR FRAME
|
TC-TE-TXC |
€
0.00
|
|
|
| 3 |
HZ00069056
|
SCREW TEF M8X1.25X20 CH12
|
|
€
0.00
|
|
|
| 4 |
HY00060898
|
SCREW TTEI M6X1X15 CH5
|
|
€
0.00
|
|
|
| 5 |
HY00073140
|
PIN, FOOTREST
|
|
€
0.00
|
|
|
| 6 |
H800096907
|
L.H. spring
|
|
€
0.00
|
|
|
| 7 |
H8000B0157
|
Engine guard (No. 7 DRAW. 19)
|
|
€
0.00
|
|
|
| 9 |
H80A089953
|
R.H. foot-rest
|
|
€
0.00
|
|
|
| 10 |
H80A089962
|
L.H. foot-rest
|
|
€
0.00
|
|
|
| 11 |
H800096908
|
R.H. spring
|
|
€
0.00
|
|
|
| 12 |
H64ND20068
|
PIN, COTTER 1.8X18
|
|
€
0.00
|
|
|
| 13 |
HZA0001815
|
WASHER 16X10.5X1
|
|
€
0.00
|
|
|
| 15 |
H80A0B0245
|
L.H. frame guard
|
|
€
0.00
|
|
|
| 18 |
H800069150
|
Plate
|
|
€
0.00
|
|
|
| 19 |
HZ00062796
|
SCREW TEF M8X1.25X40 CH12
|
|
€
0.00
|
|
|
| 20 |
H800033373
|
Rivet
|
|
€
0.00
|
|
|
| 24 |
H8000A7237
|
U-bolt
|
SMR |
€
0.00
|
|
|
| 25 |
H800087243
|
CONICAL ROLLERS BEARING
|
|
€
14.00
|
|
|
| 26 |
HZ00062796
|
SCREW TEF M8X1.25X40 CH12
|
SMR |
€
0.00
|
|
|
| 27 |
HYG0073458
|
Pin (M8x150 mm)
|
|
€
7.00
|
|
|
| 28 |
HYG0073458
|
Pin (M8x150 mm)
|
|
€
7.00
|
|
|
| 29 |
H800043391
|
Anti-left lock assy
|
SMR-TE |
€
12.40
|
|
|
| 30 |
H800024350
|
Spacer
|
SMR |
€
0.00
|
|
|
| 31 |
HY00043928
|
NUT, SELF LOCKING M8X1.25
|
|
€
0.00
|
|
|
| 34 |
H800035531
|
Raw key
|
SMR-TE |
€
0.00
|
|
|
| 37 |
H8000B0152
|
FOOTREST BRACKET KIT
|
SMR |
€
0.00
|
|
|
| 38 |
H8AA059433
|
ROLLER, CHAIN TENSIONER
|
|
€
0.00
|
|
|
| 39 |
H800063312
|
Bearing(ø8xØ22x7mm)
|
|
€
10.20
|
|
|
| 40 |
H8A0059434
|
SPACER
|
|
€
0.00
|
|
|
| 44 |
H8000B0156
|
R.H. support
|
SMR |
€
0.00
|
|
|
| 45 |
H800066652
|
R.H. foot rest support
|
SMR |
€
0.00
|
|
|
| 46 |
H8000B0155
|
L.H. holder (TE SMR)
|
SMR |
€
0.00
|
|
|
| 47 |
H800066651
|
L.H. foot rest support
|
SMR |
€
0.00
|
|
|
| 48 |
H800041459
|
Pin
|
SMR |
€
0.00
|
|
|
| 49 |
H62N115504
|
Washer
|
SMR |
€
0.00
|
|
|
| 50 |
H64ND20048
|
PIN, COTTER 1.3X12
|
SMR |
€
0.00
|
|
|
| 51 |
H800062732
|
Screw
|
SMR |
€
0.00
|
|
|
| 52 |
H8000H0233
|
STAND, SIDE
|
TE |
€
81.30
|
|
|
| 52 |
H8000H0234
|
Side stand
|
SMR |
€
0.00
|
|
|
| 53 |
H800097976
|
SCREW M8X1.25X25
|
SMR-TE |
€
0.00
|
|
|
| 54 |
H8000A0268
|
SPRING, SIDE STAND INNER
|
SMR-TE |
€
0.00
|
|
|
| 55 |
H8000A0269
|
SPRING SIDE STAND OUTER
|
SMR-TE |
€
0.00
|
|
|
| 56 |
H8000A0267
|
LINK, SIDE STAND
|
SMR-TE |
€
0.00
|
|
|
| 57 |
HU00046893
|
Clip nut
|
|
€
1.50
|
|
|
| 60 |
H8000H0188
|
R.H. crankcase guard (TE-TC-TXC) (No. 60 DRAW. 19)
|
TC-TE-TXC |
€
0.00
|
|
|
| 61 |
H8000H0187
|
L.H. crankcase guard (TE-TC-TXC) (No. 61 DRAW. 19)
|
TC-TE-TXC |
€
0.00
|
|
|
| 62 |
HZ00062730
|
SCREW TE M6X1X30 CH8
|
TC-TE-TXC |
€
0.00
|
|
|
| 65 |
H8000B1747
|
Heat protection
|
TC-TE |
€
0.00
|
|
|
| 66 |
H8E0061121
|
Screw M8-L30
|
|
€
0.00
|
|
|
| 67 |
HZ00017810
|
NUT M8X1.25 H8 CH12
|
|
€
0.00
|
|
|
| 68 |
H60ND02559
|
SCREW TCEI M8X1.25X40
|
|
€
0.60
|
|
|
| 69 |
H947200056
|
CUSHION, STAND STOPPER
|
SMR-TE |
€
34.10
|
|
|
| 70 |
H8000B0841
|
PLUG
|
|
€
0.00
|
|
|
| 71 |
H800056444
|
Clamp (188 mm)
|
|
€
0.00
|
|
|
| 72 |
H8000H0822
|
Bushing
|
TC-TE-TXC |
€
1.00
|
|
|
| 63 |
HU00046893
|
Clip nut
|
TC-TE-TXC |
€
1.50
|
|
|
| 73 |
H8000H0235
|
PIN SPRING
|
SMR-TE |
€
3.40
|
|
|
